Svantek SV 200A User Manual

12
SV 200A User Manual
1.2 GENERAL FEATURES OF SV 200A
• Noise monitoring terminal fitted in one portable instrument dedicated for unattended permanent and
short period noise monitoring
• Integrated, non-removable microphone preamplifier
• Noise measurements meeting IEC 61672-1:2013, class 1 standard
• 1/1 & 1/3 octave real-time analysis
• Audio events and wave recording
• AAC audio compression (future option)
• Statistical analysis with up to 10 percentile values
• Community and airport direction characteristics, software selectable
• Remote, automated system check (built-in acoustic actuator)
• Built-in 16 GB memory
• High efficiency windscreen
• Designed for outdoor use in all weather conditions
• Communication over 3G and WLAN/LAN networks
• GPS module
• Bluetooth module
• eCompass sensor
• Vaisala WXT5xx weather monitoring module support
• Easy connection configuration by means of SVANNET APP software
• Easy remote access over PC or Smartphone by means of SvanNET Web service
• Precise time synchronization and GPS position of the instrument
• Up to 6 days of autonomy operation (internal battery operating time with all radio modules off)
• Advanced software for data processing and reporting SvanPC++_EM
• Li-Ion 72.4 Wh rechargeable battery (non-removable)
• Direct connection of solar panel (without controller) or DC power supply
• Robust design
• Ingress Protection Rating IP 65
• Easy and fast installation in-field
• Directivity of dominant sound source detection
1.3 ACCESSORIES INCLUDED
• MK 255S Microtech Gefell, 50 mV/Pa, prepolarised ½” condenser microphone
• SB 274 waterproof external DC power supply
• SA 209 5” foam windscreen
• SC 256A USB cable
• ST 200A 4 microphones for noise direction measurements
• Anti-bird spikes
• Extension and microphone protective sleeves
• GSM and WLAN antennas
• Mounting kit
• SvanPC++_RC – Remote Communication module for SvanPC++ software (single license)
1.4 ACCESSORIES AVAILABLE (OPTIONAL)
• SV 36 Class 1 Sound Calibrator 94/114 dB @ 1000 Hz
• SB 276 solar panel
• SA 206 4 m telescopic mast
• SP 275 weather station based on Vaisala WXT53x module
• SC 209A dedicated cable for the SP 275 weather station
• SP 272 alarm lamp
• SP 200 LAN adapter
• SvanPC++_EM Environmental monitoring module for SvanPC++ software (single license)

Svantek SV 200A Specifications

General

Brand	Svantek
Model	SV 200A
Category	Measuring Instruments
Language	English
