SV 200A User Manual
7+NofDirDistXY
EnergyDistZ[i]
energy distribution calculated for i-direction to entire energy ratio
for Z axis [*10000]
7+NofDirDistXY
+NofDirDistZ
Length
length of the block together with IDs, [words]
7+NofDirDistXY
+NofDirDistZ+1
0xCF06
record ID (end)
…
…
…
B.2.13 Record with GPS data
The value equal to -12288 (0xd000) denotes the undefined value.
Word number
Name
Comment
0
0xC703
record ID (start)
1
Length
length of the block together with IDs, [words]
2
Quality
Signal quality:
0 - GPS_NOT_FIX (no signal)
1 - GPS_FIX
2 - GPS_FIX_DIF
3
Time.Sec
Seconds part of time
4
Time.Min
Minutes part of time
5
Time.Hour
Hours part of time
6
Date.Day
Day
7
Date.Month
Month
8
Date.Year
Year
9
Latitude.Deg
Degree part of latitude
10
Latitude.Min
Minutes part of latitude
11
Latitude.Sec
Seconds part of latitude
12
Latitude.MiliSec
Miliseconds part of latitude
13
Latitude.Dir
Latitude direction: N, S
14
Longitude.Deg
Degree part of longitude
15
Longitude.Min
Minutes part of longitude
16
Longitude.Sec
Seconds part of longitude
17
Longitude.MiliSec
Miliseconds part of longitude
18
Longitude.Dir
Longitude direction: E, W
19
Altitude
Altitude (meters)
20
Altitude.10
Decimal part of altitude
21
Speed
Speed * 100 (km/h)
22
Heading
degree * 10
23
HDOP
Horizontal Dilution of Precision * 10
24
Length
length of the block together with IDs, [words]
25
0xCF03
record ID (end)
…
…
….
