Svantek SV 200A - Record with System Check Data; Record with Remote Marker Data

142
SV 200A User Manual
13
RainPeakIntens
Rain Peak Intensity [mm/h]
14
HailAcc
Hail Accumulation [hits/cm2]
15
HailDuration
Hail Duration [s]
16
HailIntens
Hail Intensity [hit/(cm2*h)]
17
HailPeakIntens
Hail Peak Intensity [hit/(cm2*h)]
18
0xC9nn
nn = size of records
…
…
…
B.2.9 Record with system check data
Word
number
Name
Comment
0
0xC701
record ID (start)
1
Length
length of the block together with IDs, [words]
2
Type
system check type:
4 - system check (built-in actuator)
3
Date
date of the performed system check
4
Time
time of the performed system check
5
Result
result of the system check:
0 - failed
1 - OK
6
Factor
system check factor, [*100 dB]
7
Level
measured level of system check, [*100 dB]
8
PreBackGround
maximum level of the background noise measured before actuator
was turned on, [*10 dB]. This is a maximum value of three 1s
measurements of RMS(C)
9
PostBackGround
maximum level of the background noise measured after actuator
was turned off, [*10 dB]. This is a maximum value of three 1s
measurements of RMS(C)
10
Assigned
was the result of the system check assigned to calibration factor?
0 - No
1 - Yes
11
Length
length of the block together with IDs, [words]
12
0xCF01
record ID (end)
…
…
…
B.2.10 Record with remote marker data
Word
number
Name
Comment
0
0xC702
record ID (start)
1
Length
length of the block together with IDs, [words]
2
MarkerNr
Number of the marker (1-16, 0 - end of all block markers when
MarkerType=2)
3
MarkerType
Type of the marker:
0 - point
1 - block (start)
2 - block (end)
