Svantek SV 200A User Manual

138
SV 200A User Manual
18+NofWindDir+
NofWindMax+
NofWindAvg + 5
HailAcc
Hail Accumulation [*100 mm]
18+NofWindDir+
NofWindMax+
NofWindAvg + 6
HailDuration
Hail Duration [s]
18+NofWindDir+
NofWindMax+
NofWindAvg + 7
HailIntens
Hail Intensity [mm/h]
18+NofWindDir+
NofWindMax+
NofWindAvg + 8
HailPeakIntens
Hail Peak Intensity [mm/h]
...
...
...
Alarm parameters
Word
number
Name
Comment
0
0x0060
[60 = id, 00 = block’s length in the second word]
1
BlockLength
Block’s length
2
EventCount
Number of events
3+(7*i)..7+(
7*i)
MarkerName[i]
Marker name of i-th event (16 characters length)
8+(7*n)
Reserved
9+(7*n)
MarkerPoint[i]
Marker point of i-th event:
0 – Off
1 – On
…
…
…
B.2 RECORDS IN THE SVL LOGGER FILE
Records with results and the records with states of the markers as well as the records with breaks in the
results registration are saved in the logger files.
B.2.1 Record with the results
Content of the record with results depends on the selected measurement result and the value set in the
LOGGER position of the PROFILE x and SPECTRUM sub-lists. The following elements can be present
(in the given sequence):
(1) results of the measurement from the first profile if the corresponding LOGGER position was
active (BufferP [1] in Table B.1.11); up to four words are written:
<result1> - PEAK result, depending on the value of BufferP[1] (cf. Table B.1.11)
<result2> - MAX result, depending on the value of BufferP[1] (cf. Table B.1.11)
<result3> - MIN result, depending on the value of BufferP[1] (cf. Table B.1.11)
<result4> - RMS result, depending on the value of BufferP[1] (cf. Table B.1.11)
(2) results of the measurement from the second profile if the corresponding LOGGER position was
active (BufferP [2] in Table B.1.11); up to four words are written:
