SV 200A User Manual
EXTended I/O parameters
Word
number
Name
Comment
0
0xnn2E
[2E, nn=block’s length]
1
Mode
mode:
0 - OFF,
1 - DIGITAL IN,
2 - DIGITAL OUT
2
Function
in the case of DIGITAL IN:
0 - EXTERNAL TRIGGER
in the case of DIGITAL OUT:
0 -TRIG. PULSE,
1 - ALARM PULSE
in other cases reserved
3
ActiveLevel
in the case of DIGITAL OUT and ALARM PULSE:
0 - LOW,
1 - HIGH
in other cases reserved
4
Source
in the case of DIGITAL OUT and ALARM PULSE:
0 - PEAK(1),
1 - SPL(1),
2 - LEQ(1)
in other cases reserved
5
AlarmLevel
in the case of DIGITAL OUT and ALARM PULSE:
30 ÷ 130 dB (*10)
in other cases reserved
6
Device
device connected to EXT I/O RS232 interface:
0 - RS232 Interface,
1 - Meteo (SV205B)
2 - reserved
3 - Meteo (SV209 or SP275)
7
Reserved
reserved
8
Reserved
reserved
9
Polarisation/Slope
in the case of DIGITAL OUT and TRIG. PULSE:
Polarisation (0 - POSITIVE, 1 - NEGATIVE)
in the case of DIGITAL IN
Slope (0 - POSITIVE, 1 - NEGATIVE)
in other cases reserved
...
Special settings for profiles
Word
number
Name
Comment
0
0xnn05
[05, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm06
[06, mm=sub-block’s length]
3
DetectorP[1]
detector type in the 1
st
profile:
0 - IMP.,
1 - FAST,
2 - SLOW
4
FilterP[1]
filter type in the 1
st
profile:
1 - Z,
2 - A,
3 - C
