SV 200A can be fully controlled via SvanPC++ software, which provides also wide spectrum of data
post-processing and reporting functions.
Note: All SvanPC++ functions are well described in the SvanPC++ User Manual. In the
current manual only most useful and instrument specific functions and screens are
described.
SV 200A needs to be connected to the computer running SVAN PC++ either by USB cable, 3G, WLAN
or LAN connection. In all cases except USB, SvanPC++ should be supplemented with the Remote
Communication module.
9.1 SVANPC++ SOFTWARE INSTALLATION AND ACTIVATION
To configure SV 200A for the first time the user should use Svan PC++ software on your PC. It allows
easy control of each function of the instrument and manage whole noise monitoring station systems
consisting of more than one SV 200A device.
1. Make sure that your PC has active Internet connection if you wish to use SV 200A via the
Internet. PC should have Windows operating system. Minimum system requirements: 1GHz
CPU, 1 GB RAM (2GB RAM for x64 system), 20 GB HDD, 1024x768 display.
2. Download and install Svan PC++ software and Svantek USB Drivers from
http://svantek.com/lang-en/support/software.html.
3. Prepare the activation key for the Remote Communication (RC) module, that has been
provided with the device.
4. On the Help menu click Enter Activation Keys… option and enter the key to activate the
Remote Communication module.
5. Your Svan PC++ software is ready to use with SV 200A.
Note: Remote Communication module should be activated for each individual SVANTEK
device. Remember to enter activation key for any new device you wish to manage with the
RC module.
9.2 SV 200A CONTROL VIA USB INTERFACE
Although SV 200A is dedicated to wireless remote control it can be also easily configured and controlled
via the USB interface. The USB interface or WLAN in AP mode should be used for the first wireless
communication configuration. The USB interface can also be used in emergency, when wireless
connection was broken or when for some reason wireless communication is not possible or in situations
when the measurement process doesn’t require wireless control of the instrument.
The philosophy of the instrument control from SvanPC++ either via USB or via wireless communication
is generally the same. Therefore, this manual will be concentrated mostly on wireless instrument control.
After connecting the instrument to the computer with running Svan PC++ by SC 256A USB cable the
SV 200 instrument wizard window appears on the screen. It enables you to:
