Svantek SV 200A User Manual

132
SV 200A User Manual
5
BufferP[1]
logger contents in the 1
st
profile defined as a sum of:
0 - none,
1 - PEAK,
2 - MAX,
4 - MIN,
8 - RMS
6
CalibrFactor[1]
calibration factor (*10 dB) in the 1
st
profile
7
ProfileFlags[1]
flags in the 1
st
profile
8
0xmm06
[06, mm=sub-block’s length]
9
DetectorP[2]
detector type in the 2
nd
profile:
0 - IMP.,
1 - FAST,
2 - SLOW
10
FilterP[2]
filter type in the 2
nd
profile:
1 - Z,
2 - A,
3 - C
11
BufferP[2]
logger contents in the 2
nd
profile defined as a sum of:
0 - none,
1 - PEAK,
2 - MAX,
4 - MIN,
8 - RMS
12
CalibrFactor[2]
calibration factor (*10 dB) in the 2
nd
profile
13
ProfileFlags[2]
flags in the 2
nd
profile
14
0xmm06
[06, mm=sub-block’s length]
15
DetectorP[3]
detector type in the 3
rd
profile:
0 - IMP.,
1 - FAST,
2 - SLOW
16
FilterP[3]
filter type in the 3
rd
profile:
1 - Z,
2 - A,
3 - C
17
BufferP[3]
logger contents in the 3
rd
profile defined as a sum of:
0 - none,
1 - PEAK,
2 - MAX,
4 - MIN,
8 - RMS
18
CalibrFactor[3]
calibration factor (*10 dB) in the 3
rd
profile
19
ProfileFlags[3]
flags in the 3
rd
profile
…
RTF parameters (reserved)
Word
number
Name
Comment
0
0xnn21
[21, nn=block’s length]
1
Type [1]
reserved
2
Rank [1]
reserved
3..4
Lower pole [1]
reserved
5..6
Upper pole [1]
reserved
