SV 200A User Manual
• internal battery capacity { },
• measurement status:
o measurement is stopped { },
o measurement is running {blinking / },
• power source:
o internal battery { },
o solar panel { },
o power supply unit or external DC source { },
o power over Ethernet { },
o USB power { },
• other statuses:
o switched on actuator { },
o active GPS { , blinking when GPS is not fixed }.
Spectrum view mode
1/1 or 1/3 spectra are displayed for LEQ and MAX band results together with
three TOTAL values (TOT A, TOT C and TOT Z). The cursor shows the result
for the band or the result for TOTAL value: central band frequency, result in
dB (for LEQ spectra) and filter (A, C, B, Z) (for MAX spectra). The cursor
position can be changed with the or key.
Power Supply status view presents:
• type of the power Source: internal Battery, power supply unit (Mains),
Solar panel, USB or from the Ethernet (PoE),
• charging Status: Charging or Not Charging,
• estimated working time without charging or time to full charging of the
internal batteries (Time Left),
• the battery Charge status in %,
• battery Capacity in Ah,
• battery temperature in
o
C (Temp.).
Communication information presents:
• Interface type: 2G/3G, LAN, WLAN, BT (Bluetooth),
• Connection Status: None (if the modem is switched off), Init OK (if
the modem is switched on, but there is no connection), Internet (if the
instrument is connected to the Internet), Connected (if connection
with remote peer, but not SvanNET, has been established), SvanNET
(if the instrument has established connection with the SvanNET web-
service),
• Signal level (RSSI) in dBm or None,
• Traffic (amount of sent and received bytes since modem on),
• Modem Manufacturer,
• Modem Model,
• Internal firmware Revision of the modem,
• IMEI number of the modem,
• MAC address of the WLAN module.
