Sysmac CQM1 User Manual

3-2SectionSSS Capabilities
78
Group DescriptionName
Utility
Data Area Lists Displays lists (such as used areas and cross-references) in accordance with the
contents of the user program in the system work area.
Change
Addresses
Globally changes bit and word addresses in the user program in the system work
area.
Print Lists Prints lists, ladder diagrams, and mnemonics in accordance with the contents of
the user program in the system work area.
EPROM/Memory
Card
Writes, reads, and compares the user program between the PROM
Writer/Memory Card and system work area.
Program
Conversion
C500 → C2000H:
Converts C500-family programs to C2000H programs.
C2000H
→ CVM1:
Converts C2000H-family programs to CVM1 programs
Create Library
File
Creates a library on a floppy disk or hard disk for use as an LSS data disk.
Time Chart
Monitor
(C-series PCs
only)
Accesses the time chart monitor data produced online.
Instruction Trace
(C-series PCs
only)
Accesses the instruction trace data produced online.
Data trace Accesses the data trace data produced online.
Set Instructions
(C-series PCs
only)
Used to assign instructions to function codes in the instructions table and to save
and retrieve instructions tables to and from data disk files.
Retrieve/Save
Instr
(C-series PCs
only)
Used to save and retrieve expansion instruction sets to and from data disk files.
PC Setup Used to set the PC operating parameters in the PC Setup and to save and
retrieve PC Setups to and from data disk files.
Allocate UM
(C-series PCs
only)
Used to allocate parts of the user memory area for used as a Fixed DM Area
and/or I/O Comment Area.
Edit PC ID
(CVM1 PCs only)
Used to create, edit, search for, or print PC IDs (names).
Compare
Programs
(CVM1 PCs only)
Used to compare a program in a data disk with the program in the work file in the
computer.
Customization
(CVM1 PCs only)
Used to change bit/word names, to define custom data areas, or to register HIS
instructions.
Network Support
Table
Used to edit data link tables and routing tables for the SYSMAC NET and
SYSMAC LINK Systems.
File
M
Directory Displays a file list. Wildcard names can be used to display only desired files.
Management
Copy File Copies files on the same floppy disk or between different disks.
Change File
Name
Changes the name of a specified file.
Delete File Deletes a specified file.
LSS File
Management
Used to change between LSS-style data files and DOS-style data files.

Sysmac CQM1 Specifications

General

Manufacturer	Omron
Operating Temperature	0 to 55°C
Humidity	10 to 90% RH (non-condensing)
Power Supply	100 to 240 VAC or 24 VDC (depending on model)
Programming Language	Ladder Diagram, Instruction List
Communication Ports	RS-232C
Expansion	Expansion I/O units available
Analog I/O	Available via expansion units
Instruction Set	Basic and advanced instructions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
