Tally Dascom 2600 2610
16
3.1.4 Disassemble the Upper Housing
1) Secure the Front Cover
Flip the Front Cover to an up right position and make it securely engaged with the
hinge.
2）Disassemble the Upper Housing
There are 2 arch shape holes on the 2 inner sides near the front of the Upper
Housing.
Pry the latch, coupling the Upp er and Lower Housings, with a flat-bladed
screwdriver inserted through the left arch-shape hole. →①
Repeat prying the latch on the right side. →②
Lift the whole Upper Housing assembly. →③
Please take care of the operation panel cable on the left side while lifting
the Upper Housing.
