4.2.2 Mechanism Assembly Part List for 2610
Item
Part
Number
Description Qty Remark
1 532023 UPPER FRICTION ASSY WIDE 1
2 532166 CLAMP PRINT BAR 1
3 532581 PRINT BAR ASSY 1
4 535000 PAPER END / TOF SENSOR ASSY 1
5 532169 PAPER GUIDE WIDE 1
6 532115 GEAR M0.75 T48 2
7 532106 CAM WHEEL M1.0 2
8 532107 LEAF SPRING CAM WHEEL 2
9 532205 LOWER MAIN FRICTION SHAFT ASSY WIDE EPDM 1
10 532181 SHAFT SQUARE PAPER PATH SELECT WIDE 1
11 532104 TOOTHED SEGMENT M1.0 2
12 532019 CHASSIS SIDE PLATE LEFT 1
13 532020 CHASSIS SIDE PLATE RIGHT 1
14 532185 COVER TRANSVERSE 1
15 532080 TRANSVERSE WIDE 1
16 532170 LOWER SLAVE FRICTION SHAFT ASSY WIDE 1
17 532180 TENSION SPRING WD0.32 D5.5 L010.0 2
18 532179 LEVER SWITCH PAPER GUIDE 2
19 532175 SWITCH PAPER GUIDE 2 1
20 532174 SWITCH PAPER GUIDE 1 3
21 532177 SWITCH PAPER GUIDE 4 1
22 532176 SWITCH PAPER GUIDE 3 1
23 540010 E-RING 5.0MM JIS B285 2
24 532178 SHAFT SWITCH PAPER GUIDE WIDE 1
25 532182 FOOT 4
26 532187 CLAMP CR- MOTOR 1
27 532192 MOTOR DAMPER 1
