4.2.5 Print Module Part List for 2610
Item
Part
Number
Description Qty Remark
1 532582 PRINT HEAD CABLE ASSY WIDE 1
2 532140 PRINT HEAD ASSY 1
3 532249 RIBBON M ASK 1
4 532144 PAPER GUIDE CARRIAGE 1
5 532584 PAPER WIDTH SENSOR ASSY 1
6 535023 HORIZONTAL POSITION SENSOR ASSY 1
7 532149 PARALLELISM SLEEVE 2
8 532199 FELT TW43 1
9 532134 CARRIAGE 1
10 532210 TENSION SPRING WD0.9 D4.5 L46.45 1
11 540015 SCREW M3X4 ISO 7045 PHILLIPS 2
12 532155 BELT TENSIONER SLIDER 1
13 532120 MATING GEAR ASSY 1
14 532194 BEARING SEGMENT 3
15 532188 LEAF SPRING LOWER FRICTION 3
16 532152 SIDE PLATE LEFT PMC 1
17 532151 SIDE PLATE RIGHT PMC 1
18 532147 HEAD GAP SLEEVE 2
19 540010 E-RING 5.0MM JIS B285 1
20 540015 SCREW M3X4 ISO 7045 PHILLIPS 6
21 540020 SCREW M3X6 BH C-TYPE PHILLIPS 3
22 532060 RIBBON DRIVE ASSY 1
23 532153 BASE PLATE PMC WIDE 1
24 532208 PULLEY SHAFT ARRESTOR 1
25 532121 PULLEY ASSY 1
26 540001 TIMING BELT MXL T464 W6.4 1
27 532135 CLAMP CODE STRIPE 1
28 532139 CODE STRIPE 1/180" WIDE 1
29 532132 CARRIAGE GUIDE SHAFT D14.0 WIDE 1
30 540029
SCREW M3X10 ISO7045 + FW D6.8 T0.5 +
SW D5 T0.8
2
31 532133 RIBBON GUIDE 1
