4.2.3 Mechanism Assembly Part List for 2600
Item
Part
Number
Description Qty Remark
1 532654 UPPER FRICTION ASSY NARROW 1
2 532166 CLAMP PRINT BAR 1
3 532581 PRINT BAR ASSY 1
4 535000 PAPER END / TOF SENSOR ASSY 1
5
532560 PAPER GUIDE NARROW 1
6 532115 GEAR M0.75 T48 2
7 532106 CAM WHEEL M1.0 2
8 532107 LEAF SPRING CAM WHEEL 2
9
532233
LOWER MAIN FRICTION SHAFT ASSY NARROW
EPDM
1
10
532244 SHAFT SQUARE PAPER PATH SELECT NARROW 1
11 532104 TOOTHED SEGMENT M1.0 2
12 532019 CHASSIS SIDE PLATE LEFT 1
13 532020 CHASSIS SIDE PLATE RIGHT 1
14 532185 COVER TRANSVERSE 1
15
532225 TRANSVERSE NARROW 1
16
532240 LOWER SLAVE FRICTION SHAFT ASSY NARROW 1
17 532180 TENSION SPRING WD0.32 D5.5 L010.0 2
18 532179 LEVER SWITCH PAPER GUIDE 2
19 532175 SWITCH PAPER GUIDE 2 1
20 532174 SWITCH PAPER GUIDE 1
2
21 532177 SWITCH PAPER GUIDE 4 1
22 532176 SWITCH PAPER GUIDE 3 1
23 540010 E-RING 5.0MM JIS B285 2
24
532243 SHAFT SWITCH PAPER GUIDE NARROW 1
25 532182 FOOT 4
26 532187 CLAMP CR- MOTOR 1
27 532192 MOTOR DAMPER 1
