Bus setups Select the serial bus channel threshold
Select the serial bus channel threshold
From the Bus Setup window, select Serial from the Bus Type list and then select from the cascading list.
NOTE. The serial bus channel Threshold option is available only on instruments with one or more of
the SR- optio
ns.
To use
To change t
he voltage threshold level of the component Input, click the Threshold entry box and use the
keypad to enter a value or use the multipurpose knobs to select a voltage level.
Behavio
r
The instrument can use different voltage thresholds levels for each component.
What do you want to do next?
Learn more about b us setups. (see page 95)
Learn a bout bus configuration. (see page 148)
Learn about digital setups. (see page 87)
