MagniVu setup Using MagniVu
Using MagniVu
NOTE. The MagniVu feature is available on MSO5000 models and on D PO5000 models with option
MSOE..
Select MagniVu in one of the following ways:
Digital menu.
Horiz/Acq
menu.
Horiz/Acq > Horizontal/Acquisition Setup and click Acquisition tab.
Overview
Turn on o
r turn off MagniVu.
To use
Select MagniVu to increase the resolution.
Behavior
MagniVu gives you higher resolution to accurately determine edge placement. This helps you make
precise timing measurements on digital edges. You can see up to 32 times more detail than with normal
digital channel sampling. The MagniVu record is acquired in parallel to the main digital acquisition and is
available at any time, running or stopped. MagniVu provides an ultra high resolution view of your data
sam
pled at a maximum resolution of 60.6 ps for 10,000 points centered around the trigger.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 159
