Mask testing setups Mask testing control window (Masks tab)
Mask testing control window (Masks tab)
From the Mask menu, select Mask Setup.
Overview
Use these controls to set up a mask test. You can set the type of mask, p olarity, display, and alignment.
NOTE. The Comm Trigger is designed to work with communications mask and standard testing. Mask
testing automatically uses Communication triggers. You must install the Serial Communications Mask
Testing Option (see page 209) on some instruments before you can access the Comm triggers.
For information o n the controls, click the buttons.
What do you want to do next?
Learnmoreaboutmasksetups. (see page 219)
Learn more a bout mask test setups. (see page 221)
Serial mask testing option
Install Option MTM on DPO7000C and MSO/DPO5000 Series instruments.
Install Option MTH on DPO70000C/D, DSA70000C/D, and MSO70000C Series instruments.
Select a mask type
From the Mask menu, select Mask Setup; then open the Masks tab.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 209
