Oscilloscope Reference Flattop2 window

Flattop2 window

This window has the lowest scallop loss of any of the windows. It also has a wider resolution bandwidth

but lower side lobe attenuation. Also, it is unique because the time domain shape has negative values.

NOTE. The Fla

ttop2 window is useful for high accuracy magnitude measurements for signals that do not

require very narrow bandwidth.

774 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
