Set up a MIPI CSI-2 serial bus
NOTE. MIPI CSI-2 serial bus setup is available only on instruments with the SR-DPHY option.
From the Bus Setup window in the Config tab, select a bus from the Bus list and then select the MIPI
CSI-2 Serial bus type.
NOTE. The Components for the MIPI CSI-2 bus standard are set by the instrument.
For information o n the controls, click the buttons.
