Mask testing setups Conﬁgure mask autoﬁt

To use

Click Autoset to align the signal within the mask. This operates the same as the Autoset button on

the front

panel.

Click Defaults to return the instrument to the default autoset conﬁguration.

Click Masks to replace this control window with the Mask Testing control window.

What do you want to do next?

Go to the Mask Setup control window. (see page 209)

Learn about mask display con ﬁ guration. (see page 213)

Learn

about mask autoﬁtconﬁguration.

(see page 215)

Conﬁgure mask autoﬁt

From the Mask menu, highlight Mask Conﬁgure; then select Autoﬁt. From the Mask Testing control

win

dow, click the AutoﬁtConﬁg button.

Overview

Use this control window to conﬁgure the limits for m inimizing mask hits, return to default setting, or return

to the Mask Testing control window.

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 215
