Trigger setups Trigger on A Only (Horizontal Delay on)
Return to the Trigger Setup control window. (see page 385)
Trigger on A Only (Horizontal Delay on)
From the Trig menu, select A - B Trigger Sequence.
Overview
Use the controls in this window to define the p arameters for the A ->B Sequence trigger with Horizontal
Delay on.
For information on the controls, click the buttons.
The following screen appears on MSO/DPO5000 Series instruments:
To use
1. From the A Event tab, select the Trigger Type.
2. Configure the controls for the A Event in the trigger setup window.
