Controls and connectors Front panel overview

Front panel overview

The instrument features the following front-panel controls and connectors.

For all DPO7000C, MSO/DSA/DPO70000C, and DSA/DPO70000D models:

Only for MSO5000 and DPO5000 models:

1. DVD/CD-RW dr

ive

2. Front-panel

controls

3. USB port

4. Ground term

inal

(see page 58)

5. Recovered

data output

6. Recovered

clock output

7. Probe comp

ensation output

(see

page 56)

8. PROBE CA LIBRATION output

(see page 57)

9. Channel 1 - 4 inputs (see

page 57)

10. Auxilia

ry trigger input

(see

page 57)

For DPO7000C Series models:

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 55
