Select the SPI bus framing
NOTE. The SPI bus Framing option is available only on instruments with option SR-EMBD.
From the Bus Setup window, select the Select tab and the SPI Serial bus type.
To use
Select the framing from the drop-down list.
Select SS framing for three wire SPI decode.
Select Idle framing for two wire SPI decode.
Behavi
or
The instrument changes the framing and uses that to decode t he selected SPI bus.
What do you want to do next?
Learn more about b us setups. (see page 95)
Learn a bout bus configuration. (see page 148)
Learn about digital setups. (see page 87)
