Measurement setups Set up histograms

Set histogram box limits - vertical

1. Select a mode:

2. Specify the adjustment:

3. Enter limits:

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 295
