How to ? Use Fast Acquisitions

4. Adjust the Intensity:

a. Open the Display control window Appearance tab.

b. Rotate the front-panel Intensity knob to adjust the intensity of displayed waveforms, or click

in the Intensity FastAcq/WfmDB entry box and enter the intensity value with the keypad or

multipurpose knob.

5. Select the Color Palette:

a. Open the Display control window Colors tab.

b. Click a color palette button in the Fast/Acq WfmDB Palette. In Fast Acquisitions mode, Temp and

Spectral show more detail than the other color palettes.

c. For a deﬁnition of each color palette, click here

(see page 175).

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 577
