Tektronix SPG600 - Figure 6-4: SPG300 External Modules

Removal and Installation Procedures
6-10 SPG600 & SPG300 Sync Pulse Generators Service Manual
Figure 6-4: SPG300 external modules
Top cover
LCD module
A20 front panel board
Front chassis
GPI connector
RFI filter
