SPG600 & SPG300 Sync Pulse Generators Service Manual 2-11
Timing (Analog) Submenu
This menu allows you to adjust the selected analog output timing offset relative to
the genlock signal or the internal reference signal. Use the up (
S) or down (T)
arrow button to scroll through the menu. Figure 2-4 shows the Timing (analog)
submenu diagram.
Figure 2-4: Timing (analog) submenu diagram
Timing (SDI) Submenu
This menu allows you to adjust the timing offset of the selected serial digital output
relative to the genlock signal or the internal reference signal. Use the up (
S) or
down (
T) arrow button to scroll through the menu. Figure 2-5 shows the Timing
(SDI) submenu diagram.
Figure 2-5: Timing (SDI) submenu diagram
Select TIMING (ANALOG) in the VIDEO menu
Set the vertical timing in 1 line steps
Set the horizontal timing in 1 clock steps
Set the horizontal timing in 0.1 ns steps
TIMING : VERTICAL
0 Line (s)
TIMING : HORIZONTAL
0.0000 µsec
TIMING : FINE
0.0 nsec
Option 01 only
Select TIMING (SDI) in the Video menu
Set the vertical timing in 1 line steps
Set the horizontal timing in 1 clock steps
TIMING : VERTICAL
0 Line (s)
TIMING : HORIZONTAL
0.00
µsec
