SPG600 & SPG300 Sync Pulse Generators Service Manual 4-1
Performance Verification
This section provides procedures to verify the performance and functionality of the
sync pulse generator.
Preparation for Performance Verification
Do the following before starting the performance verification procedures:
Power On Default Settings
Before you begin the performance verification procedures, make sure that the
required instrument settings are saved in the Power On Default preset.
If the instrument settings are saved in the Power On Default preset, you can recall
the settings after the performance verification procedures are completed by turning
off and on the power.
Warm up
The sync pulse generator and test equipment must have had a warm-up period of
at least 20 minutes.
Equipment Required
Table 4-1 lists the equipment required for this procedure.
Table 4-1: Equipment required for performance verification
Item No. Minimum requirement Recommended equipment
Frequency counter 1 Frequency range: 0.1 Hz to 1250 MHz
Precision: 7 digits or higher
ANRITSU MF 1603A
Oscilloscope 1 Bandwidth: 200 MHz or higher Tektronix TDS3032B
Video measurement set 1 Tektronix VM700T Option 01/11/1S/40
Waveform vector monitor 1 Tektronix 1765
Digital audio monitor 1 Tektronix 764
TV signal generator 1 Tektronix TG700 with AGL7 Analog Genlock
module
75 Ω BNC cable 3 Length: 42 inches Tektronix part no. 012-0074-00
75 Ω feed-through terminator 1 Tektronix part no. 011-0103-02
75 Ω coaxial terminator 2 Tektronix part no. 011-0102-01
XLR cable 1 CANARE DAC01-SA
Female XLR to male
mini-XLR adapter cable
2 Standard accessories of the VM700T
Option 40
