SPG600 & SPG300 Sync Pulse Generators Service Manual 1-3
Specifications
This section is divided into two subsections. General Characteristics lists the
electrical, mechanical, and environmental characteristics of the Sync Pulse
Generator. Certifications and Compliances lists the national and international
standards to which the sync pulse generator complies.
General Characteristics
This section lists the electrical, mechanical, and environmental characteristics of
the sync pulse generator.
All listed specifications are guaranteed unless labeled with typical. Typical
specifications are provided for your convenience but are not guaranteed.
Performance Conditions
The electrical characteristics listed on the following pages are valid under the
following conditions:
The sync pulse generator must be in an environment where the temperature,
altitude, humidity, and vibration conditions are within the operating limits
described in Table 1-11 on page 1-11.
The sync pulse generator must have a warm-up period of at least 20 minutes.
The sync pulse generator must have been calibrated and adjusted at an ambient
temperature between +20 °C and +30 °C.
The sync pulse generator must be operating at an ambient temperature between
0 °C to +40 °C, unless otherwise noted.
