Tektronix SPG600 Service Manual

Performance Verification
4-2 SPG600 & SPG300 Sync Pulse Generators Service Manual
Calibration Data Report
Photocopy this form and use it to record the performance test results.
Table 4-2: SPG600 and SPG300 calibration data report
Serial Number: Cal Data: Temperature: Humidity:
Step Function Tested Minimum Cal Data Maximum
1. Subcarrier Frequency 3.5795444 MHz 3.5795464 MHz
2. Blanking Level
CH 1 -50 mV mV +50 mV
CH 2 -50 mV mV +50 mV
CH 3 -50 mV mV +50 mV
CH 4 -50 mV mV +50 mV
3. Burst Amplitude
CH 1 271.4 mV mV 286.4 mV
CH 2 271.4 mV mV 286.4 mV
CH 3 271.4 mV mV 286.4 mV
CH 4 271.4 mV mV 286.4 mV
4. Sync Amplitude
CH 1 277.1 mV mV 294.3 mV
CH 2 277.1 mV mV 294.3 mV
CH 3 277.1 mV mV 294.3 mV
CH 4 277.1 mV mV 294.3 mV
5. 48 kHz Clock Output Level (CMOS compatible)
High 2.1 V OK
Low OK 0.8 V
6. AES/EBU Serial Digital Audio Output Level (SPG600 Only)
1+2 900 mV mV 1100 mV
3+4 900 mV mV 1100 mV
5+6 900 mV mV 1100 mV
7+8 900 mV mV 1100 mV
SPG600 Option 02
7. Blanking Level
CH 5 -50 mV mV +50 mV
CH 6 -50 mV mV +50 mV
CH 7 -50 mV mV +50 mV
CH 8 -50 mV mV +50 mV
8. Burst Amplitude
CH 5 271.4 mV mV 286.4 mV
CH 6 271.4 mV mV 286.4 mV
CH 7 271.4 mV mV 286.4 mV
CH 8 271.4 mV mV 286.4 mV
