Tektronix SPG600 Service Manual

Performance Verification
SPG600 & SPG300 Sync Pulse Generators Service Manual 4-3
Step Function Tested Minimum Cal Data Maximum
9. Sync Amplitude
CH 5 277.1 mV mV 294.3 mV
CH 6 277.1 mV mV 294.3 mV
CH 7 277.1 mV mV 294.3 mV
CH 8 277.1 mV mV 294.3 mV
10. Serial Output Amplitude
SDI 1 720 mV mV 880 mV
SDI 2 720 mV mV 880 mV
11. Serial Output Rise Time (20% to 80% amplitude points)
SDI 1 0.4 ns ns 1.50 ns
SDI 2 0.4 ns ns 1.50 ns
12. Serial Output Fall Time (20% to 80% amplitude points)
SDI 1 0.4 ns ns 1.50 ns
SDI 2 0.4 ns ns 1.50 ns
SPG600 Option 03
13. Serial Output Amplitude
SDI 5 720 mV mV 880 mV
SDI 6 720 mV mV 880 mV
14. Serial Output Rise Time (20% to 80% amplitude points)
SDI 5 0.4 ns ns 1.50 ns
SDI 6 0.4 ns ns 1.50 ns
15. Serial Output Fall Time (20% to 80% amplitude points)
SDI 5 0.4 ns ns 1.50 ns
SDI 6 0.4 ns ns 1.50 ns
Table 4-2: SPG600 and SPG300 calibration data report (cont.)
Serial Number: Cal Data: Temperature: Humidity:
