SPG600 & SPG300 Sync Pulse Generators Service Manual 1-1
Product Overview
The SPG600 and SPG300 Sync Pulse Generators are designed for high stability
master sync operation. The sync pulse generators provide a wide range of accurate
reference signals including analog video, analog black burst, serial digital video,
serial digital black, and AES/EBU digital audio.
Key Features
The sync pulse generator features include:
High stability internal reference
Genlocks to the following signals:
NTSC/PAL black burst signal
1, 5, 10 MHz, and NTSC/PAL Fsc CW signals
Serial digital video signal outputs
AES/EBU serial digital audio outputs (XLR and BNC)
Overlay a logo or ID text on the color bars or test signal
Up to 16 channels of embedded audio
48 kHz word clock output
GPI (general purpose interface) for error status report and user preset
Ethernet (100 BASE-T) interface remote control
Table 1-1: Output capability of the SPG600 and the SPG300
SPG600 outputs
Signal Standard Option 02 Option 03 SPG300 outputs
Serial digital
Video 2 2 4 2
BNC audio 4 4 4 None
XLR audio* 2 2 2 2
Analog video 4 8 4 4
48 kHz word clock Yes Yes Yes Yes
* The XLR outputs can be set to either serial digital or analog audio ports.
