Menus
2-24 SPG600 & SPG300 Sync Pulse Generators Service Manual
Network Information
Submenu
This menu allows you to display all of the current network parameters. Use the up
(
S) or down (T) arrow button to scroll through the menu. Figure 2-18 shows
Network information submenu diagram.
Figure 2-18: Network information submenu diagram
Select Information in the NETWORK menu item
: IP ADDRESS
1 23 . 123.12 3 .1 2 3
: SUBNET MASK
255.254.253.252
: MAC ADDRESS
00-0-95-00-01-AE
: BROADCAST ADDR
111.255.255.255
: GATEWAY ADDR
000.000.000.000
