Specifications
SPG600 & SPG300 Sync Pulse Generators Service Manual 1-9
Figure 1-1: SPG600 dimensions
425.4 mm (16.7 in)
439.4 mm (17.3 in)
15.4 mm
(0.6 in)
13.0 mm
(0.5 in)
43.6 mm
(1.7 in)
482.5 mm (19.0 in)
544.5 mm
(21.4 in)
514.5 mm
(20.3 in)
320.7 mm
(12.6 in)
115.7 mm
(4.6 in)
