Setting Main Board Parameters after Replacement
6-34 SPG600 & SPG300 Sync Pulse Generators Service Manual
Installing the Option Key (Option 01 Only)
Perform the following procedure to install the option key for the fine timing
adjustment feature (Option 01).
1. Press the up (
S) or down (T) arrow button to select OPTION KEY.
2. Enter the option key using the following steps:
a. Press the ENTER button to enable the text entering mode. The underscore
character ( _ ) appears at the far left of the second line.
b. Press the up (
S) or down (T) arrow button to select a character.
c. Press the left (
W) or right (X) arrow button to move the underscore
character and then press the up (
S) or down (T) arrow button to select the
character.
d. Repeat step c until all of the alphanumeric number is entered.
e. Press the ENTER button to end the text entering process.
Setting the Date and Time
Perform the following procedure to set the system date and time of the instrument
using the remote interface. The system date and time are used for the SNMP error
reporting.
Refer to the SPG600 & SPG300 Sync Pulse Generators User Manual for detailed
information on how to use the remote interface.
1. Connect the instrument to a local area network via Ethernet.
2. Set the network parameters of the instrument. Refer to the SPG600 & SPG300
Sync Pulse Generators User Manual for detailed information about the
network parameters.
3. Enable Web browser access as follows:
a. Press the SYSTEM button to display the System menu.
b. Press the up (
S) or down (T) arrow button to select NETWORK.
c. Press the left (
W) or right (X) arrow button to select Setup.
d. Press the ENTER button.
NOTE. When you make a typing mistake or enter an invalid option key for your
instrument, the error message *BAD OPTION KEY* appears. If this happens,
press the CANCEL button and then repeat step 2.
