SPG600 & SPG300 Sync Pulse Generators Service Manual 2-7
Menus
This section describes all of the available sync pulse generator menus and
submenus. The following menus are available from the front-panel menu buttons:
Video menu
Audio menu
Genlock menu
System menu
Video Menu
Pressing the VIDEO button displays the Video menu. This menu lets you set output
signals, timing of the output signals, overlay, and SDI parameters. Use the up (
S)
or down (
T) arrow button to scroll through the menu. Figure 2-1 shows the Video
menu diagram. Use the left (
W) or right (X) arrow button to select functions or
submenus in each Video menu.
