AT Commands Reference Guide
80529ST10815A Rev.2– 2017-09-14
ReproductionforbiddenwithoutTelitCommunicationsS.p.A.writtenauthorization‐AllRightsReserved page199of233
where:
<arfcn>
- C0 carrier assigned radio channel (BCCH - Broadcast Control Channel).
<bsic> - base station identification code; if #CSURVF last setting is 0, <bsic> is a
decimal number, else it is a 2-digits octal number.
<rxLev> - decimal number; it is the receiption level (in dBm).
<ber> - decimal number; it is the bit error rate (in %).
<mcc> - hexadecimal 3-digits number; it is the mobile country code.
<mnc> - hexadecimal 2-digits number; it is the mobile network code.
<lac> - location area code; if #CSURVF last setting is 0, <lac> is a decimal
number, else it is a 4-digits hexadecimal number.
<cellId> - cell identifier; if #CSURVF last setting is 0, <cellId> is a decimal
number, else it is a 4-digits hexadecimal number.
<cellStatus> - string type; it is the cell status
..
CELL_SUITABLE - C0 is a suitable cell.
CELL_LOW_PRIORITY - the cell is low priority based on the received system
information.
CELL_FORBIDDEN - the cell is forbidden.
CELL_BARRED - the cell is barred based on the received system information.
CELL_LOW_LEVEL - the cell <rxLev> is low.
CELL_OTHER - none of the above e.g. exclusion timer running, no BCCH
available…etc.
<numArfcn> - number of valid channels in the Cell Channel Description.
<arfcnn> - arfcn of a valid channel in the Cell Channel Description (n is in the
range
1..<numArfcn>)
<numArfcn> - decimal number; it is the number of valid channels in the Cell
Channel Description.
<arfcnn> - decimal number; it is the arfcn of a valid channel in the Cell Channel
Description (n is in the range
1..<numArfcn>).
<numChannels> - decimal number; it is the number of valid channels in the BCCH
Allocation list; the output of this information for non-serving cells depends on last
#CSURVEXT setting:
If
#CSURVEXT=0 this information is displayed only for serving cell.
If
#CSURVEXT=1 or 2 this information is displayed also for every valid scanned
BCCH carrier.
<ban> - decimal number; it is the arfcn of a valid channel in the BA list (n is in the
range
1..<numChannels>); the output of this information for non-serving cells
depends on last #CSURVEXT setting:
Iif
#CSURVEXT=0 this information is displayed only for serving cell.
If
#CSURVEXT=1 or 2 this information is displayed also for every valid scanned
BCCH carrier.
(The following informations will be printed only if GPRS is supported in the cell)
<pbcch> - packet broadcast control channel
0 - pbcch not activated on the cell
1 - pbcch activated on the cell
