AT Commands Reference Guide
80529ST10815A Rev.2– 2017-09-14
ReproductionforbiddenwithoutTelitCommunicationsS.p.A.writtenauthorization‐AllRightsReserved page203of233
<lac> - location area code; if #CSURVF last setting is 0, <lac> is a decimal number,
else it is a 4-digits hexadecimal number.
<cellId> - cell identifier; if #CSURVF last setting is 0, <cellId> is a decimal number,
else it is a 4-digits hexadecimal number.
<cellStatus> - string type; it is the cell status
..0 - C0 is a suitable cell (CELL_SUITABLE).
1 - the cell is low priority based on the received system information
(CELL_LOW_PRIORITY).
2 - the cell is forbidden (CELL_FORBIDDEN).
3 - the cell is barred based on the received system information (CELL_BARRED).
4 - the cell
<rxLev> is low (CELL_LOW_LEVEL).
5 - none of the above e.g. exclusion timer running, no BCCH available…etc..
(CELL_OTHER).
<numArfcn> - decimal number; it is the number of valid channels in the Cell Channel
Description
<arfcnn> - decimal number; it is the arfcn of a valid channel in the Cell Channel
Description (n is in the range
1..<numArfcn>)
<numChannels> - decimal number; it is the number of valid channels in the BCCH
Allocation list; the output of this information for non-serving cells depends on last
#CSURVEXT setting:
If
#CSURVEXT=0 this information is displayed only for serving cell
If
#CSURVEXT=1 or 2 this information is displayed also for every valid scanned
BCCH carrier.
<ban> - decimal number; it is the arfcn of a valid channel in the BA list (n is in the
range
1..<numChannels>); the output of this information for non-serving cells
depends on last #CSURVEXT setting:
If
#CSURVEXT=0 this information is displayed only for serving cell
If
#CSURVEXT=1 or 2 this information is displayed also for every valid scanned
BCCH carrier.
(The following informations will be printed only if GPRS is supported in the cell)
<pbcch> - packet broadcast control channel
0 - pbcch not activated on the cell
1 - pbcch activated on the cell
<nom> - network operation mode
1
2
3
<rac> - routing area code
0..255
<spgc> - SPLIT_PG_CYCLE support
..0 - SPLIT_PG_CYCLE is not supported on CCCH on this cell
..1 - SPLIT_PG_CYCLE is supported on CCCH on this cell
<pat> - priority access threshold.
