AT Commands Reference Guide
80529ST10815A Rev.2– 2017-09-14
ReproductionforbiddenwithoutTelitCommunicationsS.p.A.writtenauthorization‐AllRightsReserved page204of233
0
3..6
<nco> - network control order.
0..2 -
<t3168> - timer 3168.
<t3192> - timer 3192.
<drxmax> - discontinuous reception max time (in seconds).
<ctrlAck> - packed control ack.
<bsCVmax> - blocked sequenc countdown max value.
<alpha> - alpha parameter for power control.
<pcMeasCh> - type of channel which shall be used for downlink measurements for
power control.
0 - BCCH
1 - PDCH
(For non BCCH-Carrier)
<arfcn>,<rxLev>
where:
<arfcn>
- decimal number; it is the RF channel
<rxLev> - decimal number; it is the receiption level (in dBm)
In 3G
<uarfcn>,<rxLev>,<mcc>,<mnc>,<scrcode>,<cellId>,<lac>,<cellStatus>
<CR><LF><CR><LF><CR><LF>
where:
<uarfcn>
- The carrier frequency is designated by the UTRA Absolute Radio
Frequency Channel Number
<rxLev> - decimal number; it is the receiption level (in dBm)
<mcc> - hexadecimal 3-digits number; it is the mobile country code
<mnc> - hexadecimal 2-digits number; it is the mobile network code
<scrcode> - decimal number; it is the scrambling code
<cellId> - cell identifier; if #CSURVF last setting is 0, <cellId> is a decimal number,
else it is a 4-digits hexadecimal number
<lac> - location area code; if #CSURVF last setting is 0, <lac> is a decimal number,
else it is a 4-digits hexadecimal number
<cellStatus> - string type; it is the cell status
..CELL_SUITABLE - C0 is a suitable cell.
CELL_LOW_PRIORITY - the cell is low priority based on the received system
information.
CELL_FORBIDDEN - the cell is forbidden.
CELL_BARRED - the cell is barred based on the received system information.
CELL_LOW_LEVEL - the cell <rxLev> is low.
CELL_OTHER - none of the above e.g. exclusion timer running, no BCCH
available…etc.
In 4G (partly implemented)
