Troubleshooting
Turf Groomer
Condition Probable Cause Remedy
Turf groomer does not engage when clutch
is engaged.
Drive belt not properly tensioned. Adjust drive belt tension. (See “Turf
Groomer Drive Belt Tension
Adjustment” on page 10-6.)
Drive belt worn, stretched, or damaged. Replace drive belt. (See “Drive Belt” on
page 10-17.)
Clutch shaft roll pin loose or broken. Replace clutch shaft roll pin. (See “Drive
Assembly” on page 10-18.)
Drive shaft roll pin loose or broken. Replace drive shaft roll pin. (See “Drive
Assembly” on page 10-18.)
Clutch spring broken. Replace clutch pin. (See “Drive Assembly”
on page 10-18.)
Turf groomer height-of-cut set too low. Adjust height-of-cut. (See “Turf Groomer
Height-of-Cut Adjustment” on
page 10-7.)
Turf groomer shaft key broken or missing. Replace turf groomer shaft. (See “Turf
Groomer Shaft Assembly” on
page 10-27.)
Turf groomer drive pulley set screw loose
or missing.
Tighten or replace groomer shaft drive
pulley set screw. (See “Drive Assembly”
on page 10-18.)
Reel clutch not engaged. Engage reel clutch. See Operator’s
Manual.
Traction/reel drive clutch faulty. Replace clutch. (See “Engine and Clutch”
on page 3-7.)
Front roller not properly aligned with turf
groomer blades.
Adjust front roller. (See “Front Roller” on
page 10-26.)
Turf groomer does not reach full speed. Turf groomer drive belt not properly
tensioned.
Adjust belt tension. (See “Turf Groomer
Drive Belt Tension Adjustment” on
page 10-6.)
Turf groomer drive belt worn, stretched, or
damaged.
Replace drive belt. (See “Drive Belt” on
page 10-17.)
Turf is being damaged when turf groomer
is engaged.
Grooming too frequently. Reduce frequency of grooming.
Turf groomer height-of-cut set too low. Adjust turf groomer height-of-cut. (See
“Turf Groomer Height-of-Cut
Adjustment” on page 10-7.)
Premature wear or failure of belt, pulleys,
and/or bearings.
Drive belt is adjusted too tight. Adjust drive belt tension. (See “Turf
Groomer Drive Belt Tension
Adjustment” on page 10-6.)
Bearings not lubricated properly. Replace damaged or faulty components
and lubricate at the intervals indicated
in the Operator’s Manual.
