3-2 4157082 First Edition
ENGINE
3
Specifications
General Engine Specifications
Engine
PGM 22
Manufacturer/Model Honda/GX120 K1QJG2
Engine Type 4-Stroke, Overhead Valve, Single Cylinder
Displacement
cu in. (cc) 7.3 (118)
Bore x Stroke
in. (mm) 2.4 x 1.7 (60 x 42)
Cooling System Forced Air
Ignition System Transistorized Magneto
PTO Shaft Rotation Counterclockwise
Recommended Spark Plug BPR6ES (NGK)
W20EPR-U (ND)
Spark Plug Gap
in. (mm) 0.028—0.031 (0.7—0.8)
