2-4 4157082 First Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Specifications
Quick Reference Specifications
General Specifications
Brakes
PGM 22
Park Brake Lever Actuating Force
lb (kg) 10 (4.5)
Park Brake Band—Anchor Pin
Center-to-Center Distance (Park
Brake Released)
in. (mm) 1.50 (38)
Cutting Unit
PGM 22
Flat Surface Height at the Front of the
Bedknife (Minimum)
in. (mm) 1/32 (0.8)
Reel-to-Bedknife Gap
in. (mm) 0.001—0.003 (0.025—0.076)
Reel Side-to-Side Clearance (Reel
Bearing Pre-Load)
in. (mm) 0.040 (1.27)
Accessories
PGM 22
Turf Groomer Drive Belt Eccentric Nut
Locking Screw Torque
lb-ft (N•m) 20 (27)
Solid Tube Roller Lock Nut Torque
lb-ft (N•m) 10—30 (13.5—40.6)
Solid Tube Roller Rotational
Resistance
lb-in
(N•m)
0—1 with no end play (0—0.11 with no end play)
Transport Tire Air Pressure
psi (kPa) 6—8 (41—55)
Engine
PGM 22
Manufacturer/Model Honda/GX-120 K1QJG2
Type 4-Cycle
Power Rating @ 4000 RPM
hp (kW) 4 (2.98)
Maximum Torque
ft-lb (N•m) 5.4 (7.5)
Operating Speed
rpm Low Idle: 1700 ± 100
High Idle: 3300 ± 100
Gasoline Specification Regular Grade Unleaded (86 Octane Minimum)
Fuel Tank Capacity
gal (l) 0.66 (2.5)
Engine Oil Specification SAE 10W-30, API Classification SF or SG
Engine Oil Capacity
qt (l) 5/8 (0.6)
