ACCESSORIES
4157082 First Edition 10-5
10
Gear Drive
Condition Probable Cause Remedy
Vertical reel/soft touch brush does not
engage when clutch is engaged.
Reel clutch not engaged. Engage reel clutch. See Operator’s
Manual.
Traction/reel drive clutch faulty. Replace clutch. (See “Engine and Clutch”
on page 3-7.)
Shifter shaft roll pin loose or broken. Replace shifter shaft roll pin. (See
“Right-Side Gear Drive—Disassembly
and Assembly” on page 10-30.)
Drive gear roll pin loose or broken. Replace drive gear roll pin. (See “Drive
Assembly” on page 10-18.)
Vertical reel/soft touch brush shaft key
broken or missing.
Replace clutch pin. (See “Repair—Vertical
Reel and Soft-Touch Brush” on
page 10-31.)
Shifter gear damaged. Replace shifter gear. (See “Repair—Gear
Drive” on page 10-29.)
Idler gear damaged. Replace idler gear. (See “Repair—Gear
Drive” on page 10-29.)
Drive gear damaged. Replace drive gear. (See “Repair—Gear
Drive” on page 10-29.)
Premature wear or failure of belt, pulleys,
and/or bearings.
Bearings not lubricated properly. Replace damaged or faulty components
and lubricate at the intervals indicated
in the Operator’s Manual.
