ELECTRICAL
4157082 First Edition 4-7
4
Wiring Harness
See Figure 4-3.
Figure 4-3
S1
E-Stop
Switch
X2 X3
X1
T1
Ignition
Coil
S2
Engine
X4
X5
On/Off
Switch
Red
Blk
Splice 1
Red
Blk Red
Red
X6
