Thermo Spectronic BioMate 3 User Manual

Field Inspection/Performance Checklist
Spectronic GENESYS 10 Series, Spectronic GENESYS 6, Spectronic BioMate 3 and
Spectronic GENESYS 10 Bio
Customer: Contact:
Phone #: S/N:
Cat. #: Date:
SPECTRONIC Standards Kit,
Certified Kit #
Initial inspection –
Appearance Good Fair Poor
Line voltage: Ground Continuity (<1ohm) Pass Fail
Revision Level (Firmware): CURRENT REVISION:
Subsystem Checks
Light centered on entrance slit Pass Fail Power up sequence Pass Fail
Light centered on sample target Pass Fail RS232 Serial Port Pass Fail
Optional Printer Pass Fail Optional Analog output Pass Fail
Not installed Not installed
Voltage Checks
Expected Measured Expected Measured
+5 (±0.25v) +12v Analog (±0.6v)
+12v (±1.2v) -12v Analog (±0.6v)
-12v (±1.2v) Lamp Voltage Vis only (5.7v to 6.1v)
Wavelength Accuracy
SPECTRONIC Standard
Expected Measured
_______ (±3nm)
Internal Wavelength Test (UV only) Internal Wavelength Test (Vis only)
Expected Measured Expected Measured
229 (±2nm) 585 (±3nm)
530 (±2nm) 807 (±3nm)
883 (±2nm)
Photometric Accuracy SRE
Expected Measured Expected Measured
_______% T (±1.2% T) 220nm UV only (≤ 0.4%T)
_______% T (±1.2% T) 340nm (≤ 0.4%T)
400nm value (≤ 0.4% T)
Comments -
FSE signature:
Date:
