Chapter 7 Spare Parts and Special Tools
Required Field Repair Fixtures/Tools
335901-400S Kit, Service alignment tools, Spectronic GENESYS 10
Which includes:
Note: The following seven items are listed as reference only. They cannot be ordered
separately.
335901-401 Target, B2 Mirror, Spectronic GENESYS 10
335901-408 Mirror, dental
335901-403 Tool, zero order grating Holder, Spectronic GENESYS 10
335901-406 Target, sample, Spectronic GENESYS 10
335901-405 Target, entrance slit, Spectronic GENESYS 10
335901-415 Spacing tool
335916-200 Single Cell Platform
942318503112 Traceable Wavelength Filters (HY and DY)
333159-000 Didymium Filter – Un-calibrated DY filter can’t be used to check instrument
performance. A traceable filter is required to check performance.
Flat-blade screwdriver
Magnetic Phillips-head (+) screwdriver (#2 bit for #4 Phillips screw)
Black cloth
Consumables
335954-000 Printer paper, pkg of 5 rolls
335923-000 Lamp Assembly, tungsten, Spectronic GENESYS 10 Vis
4062-000 Fuses
335971-000 Tubing
Battery, B-1 on the schematic
Panasonic
®
CR 1220
3 Vdc, 12mm x 2mm
Least Replaceable Units
335983-000 Analog output
335908-1610S Assy. Cable Kit,
Spectronic GENESYS 10 UVscanning/Spectronic GENESYS 6
335908-135 Assembly, grating/motor block,
Spectronic GENESYS 10 UVscanning/Spectronic GENESYS 6
335906-6024S Assembly, Main board
Spectronic GENESYS 10 UVscanning/Spectronic GENESYS 6
335902-140S Beam Splitter assembly, Spectronic GENESYS 10 UV
336001-166 Bellows for sipper door
335901-6024S Board, Main, Spectronic GENESYS 10 UV
335901-6064S Board, Main, Spectronic GENESYS 10 Vis
335906-6024S Board, Main, Spectronic GENESYS 10 UVscanning/Spectronic GENESYS 6
512-219700 Board, Ref. Detector Spectronic GENESYS 10 UV (same as Sample Det Bd)
7-1
