The display of circuits can be filtered according to a MAC address, a SAP or an id in the following
way:
show dlsw circuits mac < mac address >
show dlsw circuits sap < sap >
show dlsw circuits id < circuit id >
It is possible to display statistical information about SSP messages exchanged by the peers with the
command:
show dlsw ssp
root@Imola > show dlsw ssp
Peer:172.17.6.221 received transmitted
CANUREACH_cs - circuit start 0 1
ICANREACH_cs - circuit start 1 0
REACH_ACK - reach acknowledgment 0 1
XIDFRAME - XID frame 0 1
CONTACT - contact remote station 1 0
CONTACTED - remote station contacted 0 1
INFOFRAME - information (I) frame 3 3
CAP_EXCHANGE - capabilities exchange 2 2
Last SSP Received: INFOFRAME
Last SSP Sent: INFOFRAME
Example
The v configuration can be projected from the current router configuration.
For Example, the next figure shows:
An Imola DLSw router connected to a service LAN. The IP address assigned is 10.10.0.1.
A generic DLSw router which connects the CED LAN to the Internet. The address is
10.160.0.1
A client, with MAC address 00:0A:01:02:03:04, which communicates with a remote host
via DLC
A Host, with MAC address 00:0A:0B:0C:0D:0E, which replies to remote requests via DLC
