3. NOTE FOR OPTIONAL EQUIPMENT INSTALLATION
/MAJOR UNIT REPLACEMENT/MAINTENANCE
WARNING!
1. Turn the power off and disconnect the power cord before replacing the main parts.
2. Never perform disassembling, assembling, and cleaning just after printing. Doing so may cause you to
be injured by the print head and the inner parts of the printer being hot.
3. When cleaning the cutter, be careful not to be injured by the cutter blade.
4. Be careful not to pinch your fingers or hands with the covers.
CAUTION!
1. Fix the harnesses and the cord bushes with the cable clamp. Failure to do this may cause the covers
to catch them.
continued
Sensor Harness
Print Head Harness
Cable Clamp
Cable Clamp
Operation Panel
Harness
Stepping Motor Cable
Cord Bush
Power Switch
Power Cord
To Next Page
