4. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-33031
(Revision Date: Oct., 2018)
4.9 4” ROTARY CUTTER (B-EX206-R-QM-S)
4-61
4. Fully open the Top Cover.
5. Release the tab on the right end by pushing it, then remove the Front Panel (Right).
6. Remove the Front Panel (Left).
Tab
Front Panel (Right)
Top Cover
Front Panel (Left)
To Next Page
