Toshiba TOSVERT VF-AS3 User Manual

E6582062
6. [Advanced] How to use parameters 6-4
4
4
6
9
Memo
• When you want to output the inversion signal (OFF signal), set "7".
• The signals can be also output from the other output terminals depending on the parameter
setting.
When you want to output the signals from the [FLA]-[FLB]-[FLC] relay logic output terminals,
set at <F132: Terminal FL function>. When you want to output the signals from the terminals
[R1A]-[R1C], set at <F133: Terminal R1 function 1>. When you want to output the signals from
the terminals [R2A]-[R2C]. set at <F134: Terminal R2 function >.
• When the run command (Fwd signal or Rev signal) is OFF, the Acc/Dec completed signal is
also OFF.
Reference
• How to operate the operation panel -> Refer to [3. 1. 1.
• How to switch display mode on the operation panel -> Refer to [3. 1. 2].
• Procedure to change parameter setting -> Refer to [4. 2. 3].
• Details on operation by external signals -> Refer to [Chapter 7].

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
