Some examples may clarify how CCU will generate default IP Addresses:
Default Network Address, Network Mask and Network Mask-2
MIB LANA LANB SAT Applied at Node
192.168.0.1 / 29 192.168.0.9 / 29 10.0.255.1 / 16 HUB
0.0.0.0 / 0
192.168.0.49 / 29 192.168.0.57 / 29 10.0.0.3 / 16 RT 3
Default Network Mask and Network Mask-2 – Specify Network Address:
MIB LANA LANB SAT Applied at Node
192.100.0.1 / 29 192.100.0.9 / 29 192.100.255.1 / 16 HUB
192.100.0.0 / 0
192.100.0.49 / 29 192.100.0.57 / 29 192.100.0.3 / 16 RT 3
Default Network Address and Network Mask-2 – Specify Network Mask:
MIB LANA LANB SAT Applied at Node
192.168.0.1 / 29 192.168.0.9 / 29 10.0.3.1 / 22 HUB
0.0.0.0 / 22
192.168.0.49 / 29 192.168.0.57 / 29 10.0.0.3 / 22 RT 3
Default Network Address and Network Mask – Specify Network Mask-2:
MIB LANA LANB SAT Applied at Node
192.168.0.1 / 28 192.168.0.17 / 28 n/a HUB
0.0.0.0 / / 28
192.168.0.97 / 28 192.168.0.113 / 28 n/a RT 3
ERROR in Ver <= 31.0.1
A mismatch introduced with
KERNEL 3.0.1 (Release 3.0.1) caused an erroneous Network-
Mask when the IP address was changed.
Example: Setting
IP_ADDRESS_SAT = “10.0.3.1 / 22” would give IP address = “10.0.3.1 / 8”.
This apply to CCU version <= 31.0.1 together with
KERNEL >= 3.0.1.
Error is corrected in CCU version 31.1.0.
